Magenta’s MARK series is a line of DC fast chargers that are designed for commercial and public use. The chargers are available in a variety of power levels, from 50 kW to 350 kW. They are also available in a variety of configurations, including wall-mounted, pedestal, and cabinet-mounted.
The Mark series of chargers is known for its reliability and durability. The chargers are built to withstand the harsh conditions of outdoor use. They are also backed by a comprehensive warranty. The Mark series of chargers is a popular choice for businesses and municipalities that are looking to install EV charging stations. The chargers are easy to use and can be installed quickly and easily. They are also affordable, making them a good option for businesses on a budget.
Key Benefits
KEY
Charges EVs up to 350 kW, enabling quick full charges
Built for outdoor use, backed by a comprehensive warranty
Simple interface, easy installation, and usability
Budget-friendly choice for businesses
Key Features of the Magenta Penta
Features7.2 kW output
Type-2 gun
OLED display
With Internet communication options - Wifi/GSM/4G
Suitable for 4W
Technical specifications
SPECIFICATIONS| INPUT POWER | |
|---|---|
| Input Voltage (AC) | 3 Phase, 415V |
| Input Frequency | 50 / 60 Hz |
| Wires | 5 wires : L1,L2,L3,N,PE |
| OUTPUT POWER | |
|---|---|
| Number of Outputs | 1 |
| Output Connector | CCS-2 |
| Output Current | 200 â 1000Vdc, Max 150A |
| Output Rating | 30 kW |
| ENVIRONMENT | |
|---|---|
| Ambient Temperature | -40â°C to 85â°C |
| Operating Temperature | -30â°C to 50â°C |
| Altitude | Upto 2000 Mtr. |
| Humidity | 5 to 95% |
| PROTECTION | |
|---|---|
| Protection | Over voltage, under voltage, over current, short circuit,residual current, surge protection, earth protection at input/output, input phase reversal, over temperature, protection against electric shock |
| Compliance & Safety | IEC |
| USER INTERFACE & CONTROL | |
|---|---|
| Display | 5â TFT Touch Screen |
| Language | English |
| Emergency Stop | Mushroom type push button |
| User Authentication | RFID |
| Visual Indication | Error Indication, Presence of Input Supply |
| COMMUNICATION | |
|---|---|
| Charger & CMS | OCPP 1.6 (upgradable to OCPP2.0) |
| Network Connection | Ethernet, Sim Card (optional at additional cost) |
| MECHANICAL | |
|---|---|
| Charging Cable Length | 5 meters |
| Enclosure Protection | IK10 |
| Ingress Protection | IP54 |
| Cooling | Air Cooled |
| Dimensions (W x H x D) | 459mm x 743mm x 345mm |
